BendPak HDS18E Standard Four-Post Lift (18,000-lb. Capacity)

Incredible Truck Lift for Heavy-Duty Lifting

• BendPak's HDS-18E four-post lift is engineered to make light work out of heavy lifting. It’s built to last and it features upgrades that increase safety, durability and productivity. This is the lift that graduates from the class of mid-size trucks, vans and SUVs up to heavy-duty applications. This is a professional car lift that can even handle some industrial and farming equipment.

Extended Runways

• To accommodate long wheelbases, the HDS-18E offers extended runways that are ​249” front-to-back. This is the first of the heavy-duty models to offer extended runways. All 27K, 35K and 40K lifts are built this way. Better-gripping runways ensures the huge tires on your massive vehicles stay put. If the runways gets slick, their treaded surfaces are still able to grab the wheels without damaging or marring them.

Large Base Plates

• 12" x 12" base plates don’t just provide a solid foundation, they inspire the confidence to work on virtually any-size vehicle up to the rated weight capacity.

Dual-Hub Cable Sheaves

• Supersized 12” diameter cable sheaves within the runway and cross tubes, combined with massive 4” diameter sheave axles, dramatically improve cable wear and critical component lifespan, meaning this car lift increases your safety, so you spend less money in service-related expenses down the road.

Heavy-duty Aircraft Cable

• The HDS-18E four-post lift features four galvanized lifting cables that do an excellent job of providing abrasion resistance and preventing fatigue.

Optional Rolling Bridge Jack (two makes a set)

• Rolling jacks are used to raise the front or rear portion of a vehicle off the car lift’s runways, allowing operators to perform efficient wheel and brake service. A pair of jacks allows the entire vehicle to be elevated. Each jack has telescoping arms and frame contact pads that can be extended over the runways and positioned under vehicle lifting points. Each jack features three safety-lock positions and stackable truck and van adapters for increased lifting height and better access to frame contact points on high ground-clearance vehicles. The jacks come equipped with a commercial-grade air-hydraulic pump.

Built-In Lubrication

• Grease nipples are located on every sheave and sheave axle to make lubrication maintenance easy breezy.

Spring-Loaded Safety Locks

• Spring-loaded safety locks automatically engage continuously during rise, and adjustable safety ladders allow for precise runway leveling, even if the posts have been installed on slightly sloped floors.

Push-button Pneumatic Lock Release

• A simple push-button pneumatic lock release makes lowering operations fast and simple. Aircraft-quality stainless steel and aluminum pneumatic cylinders will provide years of trouble-free service.

Secondary Lock System

• A secondary lock system is on constant guard and acts as a slack-cable device in the unlikely event of an unexpected cable failure. Only consider a four-post lift that offers this secondary lock system.

Integrated Design

• Lifting cables, airlines, safety latches and sheaves are all fully enclosed within the structure.

Adjustable Height Locking Positions

• Features adjustable locking positions for variable-height parking and infinite leveling.

Electric-Hydraulic Power System

• A maintenance-free electric-hydraulic power system assures ultimate dependability. Despite its size and lifting capacity, all controls on the HDS-18E four-post lift are conveniently located within easy reach.
